Madhus Wheel Balancer ER10

Compact 3d balancer With Digi touch

Madhus Wheel Balancer ER10 at-a-glance

  • Automatic gauge to measure the distance and diameter of rims of up to 28”
  • Virtual Sonar for 3D measurements of wheels that, in cases of metal rims and absence of sonar, calculates the width of the rim
  • AutoAdaptive Mode – The new tolerance calculation system
  • Panel with Touch system, innovative, simple and durable. Allows intuitive use of all machine functions
  • Software programs for the professionals: SPLIT, OPT, ALU
  • ALU-S 3D Balancing mode – Adhesive weights on the internal rim planes with specific counterweight position indicator
  • Automatic approach of the wheel within 15° from the point of application of the balancing weight, to allow the operator to position it correctly
  • VDD Virtual Direct Drive – very quick and maintenance-free measurement system
  • Electromagnetic brake for the lock of the wheel in the exact weight position

Madhus Wheel Balancer ER10

Madhus Wheel Balancer ER10

Features

  • Automatic gauge to measure the distance and diameter of rims of up to 28”
  • Virtual Sonar for 3D measurements of wheels that, in cases of metal rims and absence of sonar, calculates the width of the rim
  • AutoAdaptive Mode – The new tolerance calculation system
  • Panel with Touch system, innovative, simple and durable. Allows intuitive use of all machine functions
  • Software programs for the professionals: SPLIT, OPT, ALU
  • ALU-S 3D Balancing mode – Adhesive weights on the internal rim planes with specific counterweight position indicator
  • Automatic approach of the wheel within 15° from the point of application of the balancing weight, to allow the operator to position it correctly
  • VDD Virtual Direct Drive – very quick and maintenance-free measurement system
  • Electromagnetic brake for the lock of the wheel in the exact weight position

TECHNICAL DATA

  • Single phase power supply – 115 / 230 V 50/60 Hz
  • Max. absorbed power – 0,15 kW
  • Balancing speed – 100 rpm
  • Measuring cycle for 15 kg wheel – 4.7 s
  • Measurement uncertainty – 0,5 g
  • Avarage noise – < 70 dB (A)
  • Rim width setting range – 1.5” ÷ 20” / 40 ÷ 510 mm
  • Rim diameter setting range – 10” ÷ 30” / 265 ÷ 765 mm
  • Max. wheel weight – < 75 kg
  • Machine weight – 110 kg
