Texa Konfort 712 Touch

TECHNICAL SPECIFICATIONS

Display: 7” TFT IPS 1024×600 400CD
GPU: Qualcomm© Adreno™ 308 Graphics Processing Unit (GPU) with 64-bit addressing
Touch: Capacitive touch panel, USB/12C interface
CPU:
SC200R Series Snapdragon QCM2150 Quad-core
ARM Cortex-A53 64-bit CPU @ 1.3 Ghz
STM32F103 – ARM Cortex M3 32-bit CPU

RAM: 2 GB LPDDR3
Hard disk: 16 GB eMMC
Operating system: Android 10.0
Audio peripheral: devices 1 speaker CES-703116-28PM 8ohm 2W
Wi-Fi:
802.11a/b/g/n, 150 Mbps, STA/AP/P2P
2402-2480 MHz
5 Ghz

Bluetooth:
2.1+EDR/3.0/4.1 LE/4.2 BLE
2400-2483,5 MHz

RF power: 20 dBm
I/O peripheral: devices USB 2.0 x1
Primary battery: 3 V CR2032
Secondary battery: NiMh 2,4 V – 600 mAh

Fluid / Group:
R134a / 2
R456a / 1
R1234yf / 1

Electronic refrigerant scale (Precision) [g]: ± 10
Electronic oil and UV tracer scales (Resolution) [g]:
1 (only oil drain)

Pressure transducer: Kl. 1.0
High-pressure gauge [mm]: Ø 80
Low-pressure gauge [mm]: Ø 80
Tank capacity [kg]: 10
Service pipes’ length [m]: 3

Filter assembly: 1 combined filter + mechanical filter
Compressor (airtight) [cc]: 12
Vacuum pump: 100 l/m, double stage, final pressure 0,03 mbar
Ambient temperature sensor (Resolution) [°C]: 1

Refrigerant purity [kg]: 150 (SAE J2099)
Recovery efficiency: > 95 % (SAE J2788 / SAE J2843)
Maximum operating pressure (PS) [bar]: 20
Safety device calibration [bar]: 20
Power supply voltage [V]: 230

Frequency (Hz): 50 (50 / 60)
Power [W]: 770
Operation temperature (TS) [°C]: 5 ÷ 40
Storing temperature [°C]: – 25 ÷ 60

Dimensions [mm]:
H: 1101
L: 598
P: 706

Weight [kg]: 90

The KONFORT 712 TOUCH charging stations are equipped with a 7-inch color multi-touch screen display, which gives them great usability and allows always having a clear view of the operations to perform. Moreover, the innovative graphic interface has been developed to ensure a really intuitive software user experience, making it easier to quickly read the data displayed. Data reading is best supported by the high resolution and nit’s brightness. An interesting feature is also the possibility for the operator to choose between a light or dark theme for the background. The display on the KONFORT TOUCH stations features glove-touch technology.

SIMPLE AND INTUITIVE USER INTERFACE

The interface is designed to provide all the necessary information on a single screen; this way, users can have direct access to the most useful operations. In next to no time, you will move from the initial station activation phases to carrying out the service.

The menu, which can be browsed really easily, makes the most of the large display and minimizes the “steps” required to start a charging service. Moreover, the search mode “Smart selection by model” allows you to find the vehicle you are working on by simply entering one or more keywords.

PRODUCTION AND QUALITY CERTIFIED

The KONFORT TOUCH range benefits from new developments in materials, technologies and automated production procedures that resulted in TEXA gaining an ISO TS 16949 certification.

AUTOMATIC LEAK DETECTION MANAGEMENT

The KONFORT 700 range charging stations automatically carry out a double check for possible gas leaks from the tanks. All safety-related operations take place automatically in order to eliminate errors.

ANDROID OPERATING SYSTEM EVERYTHING IS EVEN EASIER

The KONFORT TOUCH stations are designed to be extremely well-functioning and achieve the maximum simplification of the maintenance and charging operations. To reach this goal, the Android 10 embedded operating system is used. This choice allows better familiarity in activating the various controls, with a very intuitive visual language and an interface rich in infographics. The software updates are performed automatically and securely.
